2.0mm pitch 16pin ejector header With ear clasp L10.6 PC3.0 PA6T gold flash pan package

Definition of ejector header

ejector header is a connector, the two ends of the body plastic with two ear buckle, similar to the two horns of the cow and named, English name: ejector connector.
This connector is widely used in electronics, electrical appliances, instruments in the PCB circuit board, its role is to be blocked in the circuit or isolated between the circuit, to play the function of a bridge, the task of current or signal transmission.

Usually used in conjunction with female header to form a board-to-board connection; or with the electronic harness terminal to form a board-to-wire connection.
Since the specifications required for different products are not the same, there are various models and specifications of ejector header

Specification

1. Material:

High temperature insulating plastic (UL94V-0) material: PBT (only for wave soldering process).
High temperature insulation plastic (UL94V-0) materials: PA6T, PA9T, LCP (can meet the wave soldering, reflow soldering two processes).
Insulation plastic color can be divided into: black, white, blue, this color, etc.
Square pin material: brass (H65)
(Hardware contact terminal surface treatment: nickel plating first after gold or silver plating, bright tin plating, tin-free plating, semi-gold tin plating, etc.).

2. Product:

Pitch can be roughly divided into: 1.27mm, 2.00mm, 2.54mm
The number of rows can be roughly divided into: double row
Ear buckle can be roughly: long ear buckle, short ear buckle.

Product Properties

Shenzhen Soulin Electronics Technology Co., Ltd. was established in September 2009

Currently, the main products are pin header, female header, box header, aviation connector, board to board connector, SATA connector, DIN41612 connector, RJ45 and other precision connectors.

The factory with area of 6000 square and about the total number of employees 200 people and owns 32 precision mold processing equipment,35 sets high-speed precision punch,110 sets of automated assembly machines.

These products are mainly applied to vehicle monitoring, instruments and apparatus, LED display screen, Computer motherboards,Internet of Things, new energy, mobile storage and other fields.

Soulin company realizes the integrated business model of developing, manufacturing, selling and serving connectors.The Hardware Department, Injection Molding Department, Assembly Department and Square Pin Stamping Department are set up in succession.

All of products compliant“ROHS”and“REACH”,and also we can offer OEM manufacturing services and can meet customer’ demands with punctual delivery and perfect service.

Soulin company has established a long-term cooperative relationship with many domestic and foreign famous enterprises and sold products in Asia, Europe and America.

We are looking forward to setting up business partnerships with customers worldwide.

.
